Extraflame Raffaella Idro H18 5.0.16 23.6 Rated output kW steel ivory pellet stove ventilated 1294700

Extraflame Raffaella Idro H18 5.0.16 23.6 Rated output kW steel ivory pellet stove ventilated 1294700

Product type: Pellet thermal stove
Manufacturer name: Extraflame
Oven type: ventilated
Series: Raffaella Idro H18 5.0.16
Color: Ivory
Coating type: steel
Rated power: 23.6 kW
Product code: 1294700

Equipment:
- Combustion chamber made of high-strength steel
- Cast iron firebox door and combustion bowl
- Tube bundle heat exchanger (manual cleaning)
- Sealed tank
- Removable ash pan
- Front ventilation with separate motor, switchable
- Ceramic spark plug for fast ignition
- PWM-controlled circulation pump
- Thermal and water pressure protection
- 3-bar safety valve
- Expansion vessel
- Vent valve
- Pressure transmitter with display
- Rear smoke extraction optional
- FPC Plus function

Product features

1. and 2. self-balancing air
Electronically balanced primary and secondary air for optimal combustion and thermal efficiency.
Input for external room thermostat
The product is connected to the house's temperature control devices (thermostats or contacts) to achieve the desired temperature in the rooms.
Safety pressure switches for chimneys??
Check that the smoke extraction is working correctly and stop loading with pellets if necessary to avoid problems with the generator.
Chronothermostat
Chronothermostat with temperature control divided into four daily zones for optimal room control.
Automatic restart after a power outage
After a power outage, the device automatically switches back on after the required test cycle has been performed.
Clean combustion
It increases combustion efficiency and the service life of wear parts while reducing routine cleaning of the combustion chamber.
cast iron doors
The doors of the products, made from high-quality cast iron, remain unchanged over time and guarantee a constant seal.
Glass cleaning system
It is a system that effectively prevents the formation of deposits on the glass of the fire door by means of a specially preheated air path.
Removable charcoal bowl for easy cleaning
The coal basin design system allows for easy removal for quick and complete cleaning.
Self-regulation of the smoke extraction system (encoder)
It keeps the speed of the flue gas engine constant to ensure proper combustion of the product.
Leakage test at 50 Pa (100% of products)
All hermetic products, or those that only have sealed components (such as the tank), are tested under high pressure at the end of the production line to ensure safety and optimal performance.

The data reported on this website was extrapolated from the official websites of Extraflame and La Nordica; changes may be made by the parent company without prior notice. We invite you to view the updated technical specifications on the official website.

Download product sheet
